Home > Wire Extruder Machine >

Sky Blue BV BVV Wire Extruder Machine With 150kg Extrusion Output ISO Certified

Product Categories

Kunshan Fuchuan Electrical and Mechanical Co.,ltd

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

Name: Sky Blue BV BVV Wire Extruder Machine With 150kg Extrusion Output ISO Certified
Brand: Fuchuan
Price: 83300 USD

Add to Cart

China FUCHUAN BV BVV Wire Extruder Machine With 150kg Extrusion Output ISO Certified

Quick Details:

BV,BVV,BVR,RV wire extruder production line

A. Apply for extruding the PVC,PE and other plastic material for the BV,BVR insulate sheathing produced.

Characteristics:

A. PLC+IPC operation or touch screen operation, save, display and change all kinds technological parameters. Whole-process monitor.

B. Superior special non-adjusted head, meet the extruder technological parameters requirement.

C. High speed pay off equipment, assure unload the bobbin do not stop machine.

D. Special extruder screw, meet the kinds of material requirement.

Specification:

Model	FC-50	FC-60	FC-70-7	FC-80
Screw Diameter	Φ50	Φ60	Φ70	Φ80
Screw L/D Ratio	26:1	26:1	26:1	25:1
Feed wire type	Active pay off or tension pay off
Max speed(m/min)	300	300	300	200
Extrusion output	70	100	150	200
Power for main machine(KW)	15	18.5	30	37
Wire diameter	Φ0.6-4.0	Φ0.8-8.0	Φ1.5-12	Φ5.0-20
Max accumulator length(m)	220
Accumulator	Horizonal accumulator
Cooling channel	Folding W type or U type
Capstan diameter	Φ410	Φ410	Φ510	Φ610
Capstan power	3.7KW	3.7KW	5.5KW	7.5KW
Take up power	3.7KW	5.0KW	7.5KW	3.7KW reduction motor
Take up type	Double shaft take-up

Other Information

FOB SHANGHAI

Payment

TT, L/C

Delivery

FOB Shanghai/Ningbo

Origin

China

Minimum Order

1 set

Package

with container
