    1.0mm - 6.0mm Single Wire Twist Machine 1250 Touch screen+ PLC+ magnetic powder clutch

    Ask Lasest Price
    Brand Name : Fuchuan
    Model Number : FC-1250B-3
    Certification : ISO9001:2008
    Price : USD37666
    Payment Terms : T/T
    Supply Ability : 20SET/PER MONTH
    Delivery Time : 45days
    • Product Details
    • Company Profile

    1.0mm - 6.0mm Single Wire Twist Machine 1250 Touch screen+ PLC+ magnetic powder clutch

    1.0mm - 6.0mm Wire Twister Machine 1250 Frame With Disc Brake Mode


    Quick Details:


    It is applied to the twisting of PVC/PE core wire or copper wire, central bundling or side bundling.New arrival, instead of the traditional 400 tube bunching machine with high productivity(4.5times than the machine, especially for 1+6 conductors twisting), save energy, smaller size, lower noise etc.


    Characteristics:


    It is mainly used in cable laying of computer wires, such as data cable and control cable. It may synchronize central coil tapping and side coil tapping. The entire machine is consists of pay off rack, central bundler, side pay off rack for the central coil tapping set, single twist(cable-laying)machine and electrical control cabinet.


    Specifications:


    Equipment models

    FC-1250B-1

    Twisting usage

    It is applied to the twisting of above seven pcs of bare copper wires, tinned wires, silver jacketed wires ,enameled wires, and double twisting for core wires.

    Single wire dia(mm)

    φ0.20-φ2.54

    Stranding section area (mm²)

    6.0-35.0

    Core wire single wire dia

    φ3.0-φ6.0

    Core wire stranding outer dia

    φ6-φ15

    Pitch(mm)

    35-200(12zones)

    Direction of lay

    Optional for right or left

    Take up bobbin Outer dia*bore*outer width

    φ1250*φ80*950

    Max rotating speed

    800(1600twist)

    Main motor power

    22KW

    Inverter power

    22KW

    Tension control method

    Touch screen+ PLC+ magnetic powder clutch, it may ensure the constant tension from empty bobbin to full bobbin

    Magnetic powder clutch

    20kgf

    Protection

    Machine will automatically brake when wire inside and outside is broken, the machine will automatically stop when the preset length is arrived.

    Brake mode

    Electromagnetic brake

    Traversing method

    Rolling ring drive units, winding pitch and breadth are adjustable

    Operation mode

    Touch screen operation

    Dimension(mm)

    4000L*2200W*2100H


    Other Information


    FOB SHANGHAI
    Payment

    TT, L/C
    Delivery

    FOB Shanghai/Ningbo
    Origin

    China
    Minimum Order

    1 set
    Package
    with container
