1.0-3.0mm cantilever type cable making twisting bunching buncher stranding machine

Ask Lasest Price
Brand Name :	Fuchuan
Model Number :	FC-800
Certification :	ISO9001:2008
Price :	USD26000
Payment Terms :	T/T
Supply Ability :	20SET/PER MONTH
Delivery Time :	45days

Add to Cart

Product Details
Company Profile

1.0-3.0mm cantilever type cable making twisting bunching buncher stranding machine

Single Twist Copper Wire Twisting Machine 30MM - 200MM Cable Laying Equipment

Quick Details:

Applied for cable laying of computer wires, such as data cable and control cable. It may synchronize central coil tapping and side coil tapping. The entire machine is consists of pay off rack, central bundler, side pay off rack for the central coil tapping set, single twist(cable-laying)machine and electrical control cabinet.

Characteristics:

1. High production speed, constant tension from empty to full bobbin, especially for high quality stranding wire.

2. Especially for twisting small cross-section area.

3. Use synchronous belt drive,

4. Change guide wheel to change lay distance, easy to operate.

Specifications:

Equipment models	FC-500B	FC-650B		FC-650C	FC-800B
Twisting usage	Apply for twisting aerospace, medical equipment, cellphone and ultra conductor(above seven pcs of bare copper wires, tinned wires, silver jacketed wires and enameled wires),double twisting for core wires.
Single wire dia(mm)	0.08-0.45	0.15-1.04		0.12-0.52	0.38-1.70
Stranding section area (mm²)	0.05-2.5	0.35-6.0		0.30-4.0	1.0-16
Core wire single wire dia(mm)	0.5-1.5	0.5-3.0		0.5-2.0	1.0-4.0
Core wire stranding outer dia(mm)	1.0-3.5	1.0-6.0		1.0-4.0	2.0-8.0
Pitch(mm)	6.3-52.3(24classes)	11.6-100(34classes)		11.6-100(34classes)	23-147(20classes)
Direction of lay	Optional for right or left
Outer diaboreouter width	OD500 ID56 H375	OD630 ID56 H475		OD630 ID56 H475 OD630 ID127 H475	OD800 ID80 H600
Max rotating speed	3000rpm(6000twist)	2000rpm(4000twist)		2400rpm(4800twist)	1500rpm(3000twist)
Main motor power	5.5KW	7.5KW		11KW	15KW
Inverter power	5.5KW	7.5KW		11KW	15KW
Tension control method	Touch screen +PLC+ magnetic powder clutch, ensure the constant tension from empty to full bobbin
Magnetic powder clutch	1.2kgf	5kgf		2.5kgf	10kgf
Protection	automatically brake/stop 1)wire inside and outside is broken 2)the preset length is arrived
Brake mode	Electromagnetic brake
Traversing method	Rolling wire with ring drive units, winding pitch and breadth are adjustable
Operation mode	Touch screen operation
Dimension(mm)	2680L 1250W 1500H		3300L 1550W 1800H	3300L 1550w 1800H	4600L 2000W 2000H

Other Information

FOB SHANGHAI

Payment

TT, L/C

Delivery

FOB Shanghai/Ningbo

Origin

China

Minimum Order

1 set

Package

with container
